Chine Composite crusher, also known as vertical compound
crusher, is a kind of crushing machine which combining the advantages of
impact crushers and hammer crushers.
It has the characteristics of high reduction ratio, low power consumption, stable performance and easy maintenance, etc.
Technical parameter of Composite Crusher:
Model | Feed grain (mm) | Material-insize (mm) | Trening capacity (t/h) | Motor power (mm) | Maine shaft speed (mm) | Overall dimension (LxWxH) (mm) |
PEL-800 | 100 | 0-5 | 10-20 | 22 | 934 | 2100x1200x1700 |
PEL-1000 | 120 | 0-5 | 20-40 | 45-55 | 769 | 2600x1400x1900 |
PEL-1250 | 150 | 0-5 | 40-70 | 75 | 530 | 2800x1600x2100 |
PEL-1500 | 180 | 0-5 | 70-100 | 90-110 | 495 | 3100x1900x2200 |
PEL-1750 | 200 | 0-5 | 130-190 | 132-160 | 424 | 3710x2360x2390 |
PEL-2000 | 220 | 0-5 | 200-260 | 185 | 370 | 4100x2660x2620 |
Note:This is just reference,if you want to know more please contact us to get offer and process.
For different ore, choose different internal structure, we provide customized service!
Applications of Composite Crusher:
Our compound crusher is mainly used to crush cement raw materials and
cement clinker. It can also be applied to crush iron ore, sandstone,
plaster, coal gangue, lump coal, limestone, dolomite, granite, basalt
and other stones. Composite crusher is a kind of no screen, adjustable
fine crushing machine. It is optimal designed on the basis of advanced
fine crushing technology both at home and abroad. It is mainly adapted
to medium-sized raw materials and clinkers , at the same time can also
be used for fine-crush dolomite, coke precious stones, lead-zinc,
serpentine, blast furnace slag, coal gangue , phosphate rock materials
with medium hardness , especially suitable for hard limestone, dolomite,
granite, basalt artificially build sand or highway pavement stone
processing.
